Descriere
| Numar porturi | 8x RJ-45 |
| Porturi | 8x RJ45 |
| Viteza de transfer | 10/100 Mbps |
| Putere consumata | 2.64 W |
| Dimensiuni | 124.6 x 48.7 x 22.8 mm |
| Memorie Buffer | 768 KB |
| Adrese MAC | 2 K |
Detalii
SKU
LS1008
Categorii
Brand
Forwarding rate
1.2 Mpps
Installed SFP modules quantity
0
Installed SFP+ modules quantity
0
Auto MDI/MDI-X
Yes
Jumbo frames support
Yes
Switching capacity
1.6 Gbit/s
Jumbo frames
2000
Packet buffer memory
0.75 MB
Store-and-forward
Yes
Auto-negotiation
Yes
Power supply included
Yes
Power source
DC
Switch type
Unmanaged
10G support
No
Heat dissipation
9.002 BTU/h
LAN port type
FastEthernet
Product colour
White
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
0 - 40 C
Storage temperature (T-T)
-40 - 60 C
Package height
84 mm
Package depth
12.9 mm
Package type
Box
Package width
82 mm
Width
124.6 mm
Height
22.8 mm
Depth
48.7 mm
Storage relative humidity (H-H)
5 - 90%
Package weight
170 g
Certification
CE, FCC, RoHS
Wall mountable
No
Networking standards
IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Power over Ethernet (PoE)
No
LED indicators
Activity, Link, Power
Quick start guide
Yes
MAC address table
2000 entries
Housing material
Plastic
Input voltage
5 V
Power consumption (max)
2.64 W
Input current
0.6 A
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Fast Ethernet (10/100)
Power connector
DC-in jack
Harmonized System (HS) code
85176990
Flow control support
Yes
