Switch D-Link Gigabit DGS-1100-24PV2, 24 port, 10/100/1000 Mbps

D-LINK
2.402,99 RON
Costurile de livrare nu sunt incluse
D-LINK
Cod produs - SKU DGS-1100-24PV2
Adauga la Favorite

Descriere

Numar porturi

24x RJ-45
Porturi

24x RJ45
Viteza de transfer

10/100/1000 Mbps
Management

Da
Putere consumata

131.5 W
Alimentare

100 - 240 V
PoE

Da, 12 porturi PoE
PoE Budget

100 W
Dimensiuni

280 x 230 x 44 mm
Greutate

2 Kg
Montare in rack

1U
Functii LED

Power, Link, Activity, Speed
Memorie Buffer

4.1 MB
Memorie

Flash: 16 MB
Adrese MAC

8K
Metoda forwarding

35.71
Routing/Switch Fabric

48 Gbps
Standarde

IEEE 802.3, IEEE 802.3x, IEEE 802.3az

Detalii

SKU
DGS-1100-24PV2
Categorii
Switch-uri
Brand
D-LINK
AC input voltage
100 - 240 V
IGMP snooping
Yes
Total Power over Ethernet (PoE) budget
100 W
Forwarding rate
35.71 Mpps
Rack mounting
Yes
Installed SFP modules quantity
0
Installed SFP+ modules quantity
0
Auto MDI/MDI-X
Yes
Jumbo frames support
Yes
Switching capacity
48 Gbit/s
Jumbo frames
9216
Packet buffer memory
4.1 MB
Store-and-forward
Yes
Copper ethernet cabling technology
10BASE-T, 10BASE-TX, 1000BASE-T
Auto-negotiation
Yes
Switch layer
L2
Switch type
Managed
Multicast support
Yes
Virtual LAN features
Port-based VLAN, Voice VLAN
Port mirroring
Yes
Number of VLANs
128
10G support
No
Broadcast storm control
Yes
Link aggregation
Yes
Power over Ethernet plus (PoE+) ports quantity
12
DHCP features
DHCP client
Heat dissipation
107.5 BTU/h
Memory type
DRAM
Fanless
Yes
Rate limiting
Yes
Spanning tree protocol
Yes
Power over Ethernet (PoE) power per port
30 W
Queue scheduling algorithms
SPQ, Weighted Round Robin (WRR)
Noise level
0 dB
Number of queues
4
Head-of-line (HOL) blocking
Yes
LAN port type
Gigabit
Operating altitude
0 - 2000 m
Product colour
Black
Quality of Service (QoS) support
Yes
Processor frequency
125 MHz
Flash memory
16 MB
Built-in processor
Yes
Security algorithms
SNMP, SSL/TLS
Operating relative humidity (H-H)
0 - 95%
Operating temperature (T-T)
-5 - 50 C
Storage temperature (T-T)
-40 - 70 C
Width
280 mm
Height
44 mm
Depth
230 mm
Storage relative humidity (H-H)
0 - 95%
Weight
2.2 kg
Certification
EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCC cUL, CE LVD, CB, BSMI, CCC
Power over Ethernet (PoE)
Yes
LED indicators
Yes
Web-based management
Yes
System event log
Yes
MAC address table
8000 entries
Power consumption (max)
19.5 W
VLAN support
Yes
Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Harmonized System (HS) code
85176990
Mean time between failures (MTBF)
255003 h
Full duplex
Yes
Flow control support
Yes
